QCPlot::QCPLayerable Class Reference

Base class for all objects that can be placed on layers. More...

Inheritance diagram for QCPlot::QCPLayerable:

Public Member Functions
	QCPLayerable (QCustomPlot *parentPlot)
	Creates a new QCPLayerable instance. More...
bool	visible () const
QCustomPlot *	parentPlot () const
QCPLayer *	layer () const
bool	antialiased () const
void	setVisible (bool on)
	Sets the visibility of this layerable object. More...
bool	setLayer (QCPLayer *layer)
	Sets the layer of this layerable object. More...
bool	setLayer (const QString &layerName)
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Sets the layer of this layerable object by name. More...
void	setAntialiased (bool enabled)
	Sets whether this object will be drawn antialiased or not. More...

Protected Member Functions
bool	moveToLayer (QCPLayer *layer, bool prepend)
void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const
virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const =0
virtual QRect	clipRect () const
virtual void	draw (QCPPainter *painter)=0

Protected Attributes
bool	mVisible
QCustomPlot *	mParentPlot
QCPLayer *	mLayer
bool	mAntialiased

Friends
class	QCustomPlot

Detailed Description

Base class for all objects that can be placed on layers.

This is the abstract base class most visible objects derive from, e.g. plottables, axes, grid etc.

Every layerable is on a layer (QCPLayer) which allows controlling the rendering order by stacking the layers accordingly.

For details about the layering mechanism, see the QCPLayer documentation.

Constructor & Destructor Documentation

QCPlot::QCPLayerable::QCPLayerable

(

QCustomPlot *

parentPlot

)

Creates a new QCPLayerable instance.

Since QCPLayerable is an abstract base class, it can't be instantiated directly. Use one of the derived classes.

Member Function Documentation

void QCPlot::QCPLayerable::setAntialiased

(

bool

enabled

)

Sets whether this object will be drawn antialiased or not.

Note that antialiasing settings may be overridden by QCustomPlot::setAntialiasedElements and QCustomPlot::setNotAntialiasedElements.

bool QCPlot::QCPLayerable::setLayer

(

QCPLayer *

layer

)

Sets the layer of this layerable object.

The object will be placed on top of the other objects already on layer.

Returns true on success, i.e. if layer is a valid layer.

bool QCPlot::QCPLayerable::setLayer

(

const QString &

layerName

)

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Sets the layer of this layerable object by name.

Returns true on success, i.e. if layerName is a valid layer name.

void QCPlot::QCPLayerable::setVisible

(

bool

on

)

Sets the visibility of this layerable object.

If an object is not visible, it will not be drawn on the QCustomPlot surface, and user interaction with it (e.g. click/selection) is not possible.

---

The documentation for this class was generated from the following files:

• DataVisualizer/qcustomplot.h
• DataVisualizer/qcustomplot.cpp
